DAQpp::Module Class Reference
[DAQ++ objects]

class Module. More...

#include <Module.h>

Inheritance diagram for DAQpp::Module:

Inheritance graph
Collaboration diagram for DAQpp::Module:

Collaboration graph

List of all members.

Public Member Functions

 Module (const DAQid &id)
virtual ~Module ()
virtual int PrepareForRun ()=0
 Prepares for a new run.
virtual int Start (int mode=0)=0
 Start the run.
virtual int Stop (int mode=0)=0
 Stop the run.
virtual int Pause ()=0
 Pause the run.
virtual int Continue ()=0
 Resume the run after pause.
virtual int Reset ()=0
 Send a reset to the module.
virtual int GetReady ()=0
 Initialize the Module.
virtual int Trigger ()=0
 Issues a trigger.
virtual void flush ()=0
 Flush any remaining data on the Module.
virtual bool hasData ()=0
 Returns true if the Module has data available.
virtual char * getData (int &size)=0
 Retrieves the Module's data.
virtual char * allocate (int size)
 Data allocator.
virtual void deallocate (char *ptr)
 Data deallocator Deallocates the memory holding the data of a given event.
bool is_global ()
 true if the module is in global mode
void in_global (RunCommand *rc=0)
 Set the Module in global mode.
bool is_local ()
 true if the module is in local mode
void in_local ()
 Sets the Module in local or standalone mode.
void RegisterDAQ (RunCommand *rc)
 Registers to a RunCommand.
void UnRegisterDAQ (bool reset=false)
 Unregister from the RunCommand that controls this Module.

Static Public Member Functions

static char * allocate_real (int size)
 Real Data allocator.
static void deallocate_real (char *ptr)
 Real data deallocator.

Private Member Functions

void init ()
 Module initialization.
void update (Observable *o, Argument *arg)
 Receives DAQ commands.

Private Attributes

 Pointer to RunCommand.
bool local
 true if module in local or standalone DAQ mode, false otherwise

Static Private Attributes

static std::allocator< char > data_allocator
 The module memory allocator.
static std::map< void *, int > allocator_map
 The allocator map.

Detailed Description

class Module.

This class represents a module.

It is an abstract class that provides the basic DAQ commands:

All those operations are pure virtual methods on Module. That means the user must derive a class from Module and implement those methods.

It is an Observer of RunCommand. To react to DAQ commands one needs to register the Module to a RunCommand. It can also handle a RunState that will display any change in the running conditions. The RunState is set at construction. If none is give it will build a generic one.

It will destroy the RunState, but it wont't do anything to the RunCommand pointer.

A Module derives from ParameterHolder and, therefore, can mantain a list of named Parameters. The use of named parameters assumes the knowledge of the Parameter type.

Carlos Lacasta Llacer

Member Function Documentation

void Module::init (  )  [private]

Module initialization.

If the RunState pointer in the constructor is NULL it will create a new one. It will also add the module to the list of the DAQmanager.

References DAQpp::DAQmanager::addModule(), DAQpp::DAQObject::get_id(), DAQpp::DAQObject::GetStatus(), DAQpp::RunState::set_name(), and DAQpp::DAQmanager::theDAQmanager().

Referenced by Module().

void DAQpp::Module::update ( Observable *  o,
Argument arg
) [private, virtual]

virtual char* DAQpp::Module::getData ( int &  size  )  [pure virtual]

Retrieves the Module's data.

This method is used by the RunManager controling this module to retrieve the data.

{The memory needed to store the event data should be obtained with allocate().}
size returns the size of the data block
pointer to the data block.

Referenced by DAQpp::RunManager::ModuleAcquire::operator()().

static char* DAQpp::Module::allocate_real ( int  size  )  [inline, static]

Real Data allocator.

This is a static method to allocate memory for the module.

size The size in chars of the memory needed.

References allocator_map, and data_allocator.

Referenced by allocate().

static void DAQpp::Module::deallocate_real ( char *  ptr  )  [inline, static]

Real data deallocator.

ptr The memory pointer. The size is obtained from datallocator_map

References allocator_map, and data_allocator.

Referenced by deallocate().

virtual char* DAQpp::Module::allocate ( int  size  )  [inline, virtual]

Data allocator.

Allocates the memory needed to store the data of a given event. This function can be overloaded in order to change the memory management inside the module. In that case one may also need to overload deallocate correspondingly.

size The size in chars of the memory needed.

References allocate_real().

virtual void DAQpp::Module::deallocate ( char *  ptr  )  [inline, virtual]

Data deallocator Deallocates the memory holding the data of a given event.

ptr the pointer to the memory chunck
Both parameters are the same as the values given by Module::getData.

References deallocate_real().

Referenced by DAQpp::RunManager::ModuleAcquire::operator()().

void DAQpp::Module::in_local (  )  [inline]

Sets the Module in local or standalone mode.

It will run with a new RunManager that will only handle this Module.

References cmd, local, and UnRegisterDAQ().

void DAQpp::Module::RegisterDAQ ( RunCommand rc  )  [inline]

Registers to a RunCommand.

This is usually a RunManager that will displach all the commands.

References cmd.

Referenced by DAQpp::RunManager::addModule(), and in_global().

Member Data Documentation

Pointer to RunCommand.

It will store the pointer until it is changed with RegisterDAQ. This should allow to set in local and global on the same RunManager.

Referenced by in_global(), in_local(), RegisterDAQ(), UnRegisterDAQ(), and update().

std::allocator< char > Module::data_allocator [static, private]

The module memory allocator.

In DAQ++, the module is reponsible to allocate memory for the data that it will pass to the RunManager. In order to avoid leaks, DAQ++ is designed so that memory allocation in the module is done through the methods allocate and deallocate. When the RunManager writes the data sent by the Module, it will deallocate the memory.

It may be of interest for some applications to extend the lifetime of the Module data. In that case, the Module instance can overload deallocate so that the RunManager action takes no effect and deallocate the data afterwards with deallocate_real, which is defiend to be static.

Referenced by allocate_real(), and deallocate_real().

std::map< void *, int > Module::allocator_map [static, private]

The allocator map.

Module mantains a map in which the addresses and sizes of the memory chuncks allocated are stored. That avoids having to remember outside Module the size of the memory chuncks allocated.

Referenced by allocate_real(), and deallocate_real().

The documentation for this class was generated from the following files:
