DAQpp::RunState Class Reference
[DAQ++ objects]

#include <RunState.h>

Inheritance diagram for DAQpp::RunState:

Collaboration diagram for DAQpp::RunState:

List of all members.

Public Types

enum StatusType {
  NotDefined, NotReady, GettingReady, Ready,
  Starting, Paused, Running, Stopping,
  Stopped, TimeOut, last_state
}

Posible state values. More...

Public Member Functions

RunState ()

Constructor.

RunState (const RunState &s)

Copy constructor.

RunState & operator= (const RunState &s)

Asignment operator.

virtual ~RunState ()

Destructor.

const std::string & get_name () const

returns the name of the RunState

void set_name (const std::string &s)

sets the name of the RunState

void reset ()

Resets the internal counters.

void start ()

Starts the timer.

void stop ()

Stops the timer.

int Ntrig () const

returns the number of triggers

void new_trigger ()

Increases the number of triggers.

void new_writen ()

Increases the number of saved events.

int Nwriten () const

Returns the number of saved events.

double eff () const

Returns the efficiency.

double rate (bool average=false) const

Returns the acquisition rate.

double time () const

Returns the time elapsed since the start.

double get_throughput () const

returns the throughput

void reset_throughput ()

resets the throughput counter

void set_throughput (int x)

sets the throughput counter to a given value

StatusType get_status () const

Returns the current status.

bool isRunning () const

Returns true if the object is running.

bool isReady () const

Returns true if the object's state is Ready.

bool isPaused () const

Returns true if the object's state is Paused.

bool isNotReady () const

Returns true if the object's state is NotReady.

bool isTimeout () const

Returns true if the object's state is TimeOut.

StatusType set_status (StatusType st)

Sets the current status.

void update (Observable *o, Argument *arg)

Receives a request to change status.

void addAction (RunStateAction *)

Adds an action.

void deleteAction (RunStateAction *)

Deletes an action from the list.

void clearActionList ()

Clears all the action list.

void executeActionList ()

Execute all the actions in the action list.

Static Public Member Functions

static std::string const & status_str (StatusType st)

Returs the state as a string.

Static Public Attributes

static std::string str_state [last_state]

array with the names of the possible states

Private Types

typedef std::set
< RunStateAction * > ActionList

generic type for the list of actions

Private Member Functions

void cpy (const RunState &s)

Private Attributes

std::string name

name of the RunState

int ntrig

Number of triggers.

int nwriten

Number of events writen.

int throughput

Throughput.

StatusType status

State.

GTimer timer

A timer used internally to compute rate, run duration, etc.

int ntrg0

Internal buffer.

double tim0

Internal buffer.

ActionList action_list

List of actions to be made at update time.

Classes

struct executeAction

This is a unary function that will be executed on every RunAction after update. More...

Detailed Description

class RunState.

This class mantains the information about the status of a DAQ object. The status can be any of:

NotDefined,
NotReady,
GettingReady,
Ready,
Paused,
Starting,
Running,
TimeOut,

This class derives both from an Observer and Observable. As an Observable, it will notify any change of state to any of the subscribed Observers. As an Observer, the situation is a bit confusing and should probably need reconsideration. In the update method it expects as argument a pointer to an

 Arg<StatusType>

On receipt of the notification it will change the state to the one given in the argument.

It provides methods to access some other information about the DAQ object, like the number of triggers, the number of events saved, the run duration time, the efficiency, the rate, etc.

It also mantains a list of RunStateAction. Those objects represent an action that could be executed at request. The list of Actions is mantained by addAction(),deleteAction(),clearActionList(), executeActionList().

The idea of this list of actions is to be able to make some operations, like monitoring, in an authomatic way. One could think on actions like:

class UpdateWidget : public RunStateAction {
   private:
      RunState *_state;
      GtkWidget *_wdgt;

   public:
      UpdateWidget(GtkWidget *w, RunState *s=0)
  : _wdgt(w),_state(s) {}
      GtkWidget *wdgt() { return _wdgt; }
      RunState *state() { return _state; }
};

class UpdateLabel : public UpdateWidget {
   private:
      string str
   public:
      UpdateLabel(GtkWidget *w, RunState *s=0)
  : UpdateWidget(w,s),str("label") {}
      void execute() {
  gtk_label_set_text(GTK_LABEL(wdgt),str.c_str());
      }
};

and similarly with classes like UpdateButton, UpdateSlider, etc.

Author:: Carlos Lacasta

Member Enumeration Documentation

enum DAQpp::RunState::StatusType

Posible state values.

Enumerator:

NotDefined	state undefined
NotReady	not ready for run, needs a GetReady command
GettingReady	the object is initializing
Ready	the object has been initialized and is ready to run
Starting	the acquisition has just started and the object is preparing to acquire
Paused	the object is acquiring but the acquisition has been paused
Running	the object is acquiring
Stopping	the object is closing the acquisition
Stopped	the object has closed the acquisition
TimeOut	the object does not respond

Member Function Documentation

void DAQpp::RunState::reset ( )

Resets the internal counters.

It will reset the run duration time, the number of triggers, saved events, etc.

References ntrig, nwriten, DAQpp::GTimer::reset(), throughput, and timer.

Referenced by RunState(), DAQpp::RunManager::Start(), and DAQpp::Module::update().

double DAQpp::RunState::eff ( ) const

Returns the efficiency.

The Efficiency is defined as the ration between saved events and number of triggers.

References ntrig, and nwriten.

double DAQpp::RunState::rate ( bool average = false ) const

Returns the acquisition rate.

It provides the acquisition time. It can be the average rate over the whole acquisition period, if average is true, or the instantaneous rate if average is false.

References isRunning(), ntrg0, ntrig, tim0, and timer.

void DAQpp::RunState::update	(	Observable *	o,
		Argument *	arg
	)			`[virtual]`

Receives a request to change status.

This is the method call by any observable for which the RunState has subscribed for notifications. It expects as agument a pointer to an

 Arg<StatusType>

Implements Observer.

References set_status().

Member Data Documentation

std::string DAQpp::RunState::str_state [static]

Initial value:

 {
            "NotDefined",
            "NotReady",
            "GettingReady",
            "Ready",
            "Starting",
            "Paused",
            "Running",
            "Stopping",
            "Stopped",
            "TimeOut"
        }

array with the names of the possible states

Referenced by status_str().

The documentation for this class was generated from the following files:

RunState.h
RunState.cc
